The K8s/cicd/ directory hosts everything developers need to run workflows, quality scans, and build-time policies inside the IDP.

This page shows the component view of the CI/CD part of the developer‑facing stacks.

Components

Component	Path	Highlights
Argo Workflows	K8s/cicd/argo-workflows/	Workflow controller + server with metrics + RBAC locked to cicd namespace.
Governance manifests	K8s/cicd/governance/	ResourceQuota + LimitRange to keep demo workloads lightweight.
SonarQube	K8s/cicd/sonarqube/	Community edition with Vault-managed admin password + monitoring passcode.

Repo wiring & tasks

The ApplicationSet in K8s/cicd/applicationset-cicd.yaml watches K8s/cicd/* and generates Applications per subfolder. Deploy only the CI/CD stack with task stacks:cicd (after bootstrap). Secrets are seeded from Vault using External Secrets with defaults from config.toml (passwords.sonarqube_*) or generated by vault:generate-secrets.

Workflow Execution Flow

Source: cicd-workflow-execution.d2

Secrets & Credentials

Argo Workflows authenticates to Vault-backed secrets via External Secrets (see K8s/cicd/argo-workflows/values.yaml and IT/external-secrets/). SonarQube admin and monitoring tokens come from Vault and are injected by Helm after ESO syncs the secret. Additional CI secrets follow the same pattern: define them in Vault, sync via ExternalSecret, and mount as environment variables in workflow pods.

Observability Hooks

Workflow controller metrics are scraped by Prometheus via ServiceMonitor and surfaced in Grafana. Argo emits Kubernetes events that Fluent-bit ships to Loki for centralized log tailing. SonarQube exposes readiness/liveness probes along with JVM metrics for dashboards tracking quality gates and scan times.

Verify

• Workflows UI: https://workflows.<ip-dashed>.nip.io via Gateway
• SonarQube UI: https://sonarqube.<ip-dashed>.nip.io
• Controller healthy: kubectl -n cicd get deploy argo-workflows-controller

Extending the Stack

1. Add Workflows – store reusable templates under K8s/cicd/argo-workflows/templates/ (or similar), include them via ConfigMaps, and reference them in Workflow manifests.
2. Add Build Tools – create subdirectories (e.g., kaniko/, tekton/) and update applicationset-cicd.yaml so ArgoCD auto-syncs them.
3. Expose CI Services – enable Ingress/Gateway entries in values files to expose SonarQube or Argo Workflows UI via the platform Gateway.
4. Integrate pipelines – Wire Argo Events sensors (see K8s/events/*) or GitHub webhooks to trigger workflows automatically via the event mesh.

Example: Quality Gate Workflow

Keep this as a concise stage map (not a sequence diagram) to explain gate placement:

• Code → Build & Test → SonarQube Scan → Quality Gate
• Pass → proceed to GitOps Merge; Fail → return to Code.

In Argo Workflows, this becomes a DAG (build → sonarqube-scan → quality-gate) using the Vault-provisioned monitoring token.
